1200 Degrees Auto Sliding Tube Furnace Horizontal Furnace Resistance Heating

Name: 1200 Degrees Auto Sliding Tube Furnace Horizontal Furnace Resistance Heating
Brand: Huaemw
Price: 1 USD

Brand Name : Huaemw

Model Number : HY-ZGS1512E

Place of Origin : China

MOQ : 1 PCS

Price : Negotiable

Delivery Time : 1~12weeks

Heating Source : Microwave & Electric

Working Temperature : 0~1150℃

Key Features : Slideable

Static Ultimate Vacuum Degree : ≤100Pa

name : High Temperature Slideable Tube Furnace

warranty : 1 year

Contact Now

1200 Degrees, Automatically Sliding Tube Furnace HY-ZGS1512E, Resistance Heating

Product Features

HY-ZGS1512E is high temperature slideable tube furnace with rapid heating and cooling rates and high precision temperature control system.

The most important characteristics of HY-ZGS1512E is as follows,

Electric and microwave mixed heating system will ensure more stable and uniform heating.

Sliding rails are installed on the furace rack to allow the furnace chamber to move automatically from one side to another.

Sliding length: 1200mm

Sliding system is controlled by temperature controller, the furnace chamber will slide from side to side when reaching a certain temperature.

Applications

HY-ZGS1512E tube furnace is be applied to a range of applications that require processing flexibility with fast heating and cooling rates and is specially suitable for producing graphene or carbon nanotubes.

Technical Parameters

Parameters		HY-ZGS1512E
Power	Voltage	380V±10V 50Hz
	Rated Power	7KW
	Electrical Heating Power	3KW
Microwave System	Microwave Output Power	0.10~1.40KW continuously adjustable
	Microwave Frequency	2.45GHz
	Microwave Leakage Prevention	microwave leakage intensity <2mW/cm²
Thermal Insulation System	T_max	1200°C
	Working Temperature	0~1150°C
	Heating Space (diameter×width)	Φ40×130mm
Temperature Control System	Temperature Measurement Method	thermocouple
	Temperature Measurement Range	0°C~1300°C
	Temperature Control Precision	±0.1%
Control System	Auto, Manual and Isothermal Controlling Mode, PLC+Touch Screen	40 segments of programmable technical parameters, data storage and export, real-time curve data display, dynamic data display
Atmosphere System	Static Ultimate Vacuum Degree	≤100Pa
Atmosphere System	Atmosphere Range	quick pre-vacuum pumping, capalble of oxidizing gas, inert gas, weak reducing gas etc.
Safety System	Magnetron Alarm	over temperature alarm
Safety System	Furnace Door Protection Alarm	furnace door shutdown sensor
Overall Dimension	Furnace Body(L×W×H)	ca. 530×1000×1200mm
Overall Dimension	Rack(L×W×H)	ca. 900×1200×1500mm

Product Tags:

horizontal tube furnace

vertical tube furnace

Quality 1200 Degrees Auto Sliding Tube Furnace Horizontal Furnace Resistance Heating for sale

1200 Degrees Auto Sliding Tube Furnace Horizontal Furnace Resistance Heating Images
